EZ-400

I downloaded plans for the EZ-400 ( Eee-zee-400 ) from here. I must say, this is simply a great flier! What a treat! It's fast, build it and check out it's roll rate!! WOW! I've flown mine a number of times, landings are quite hot, unless there's heavy wind. It flies inverted as well as it flies right side up. Aileron control is simply +ve, great high speed turns! I love this model! Climbs out at 45°! Immense climb... what are you waiting for...go build one!! Long flights are possible. A flight full of aerobatics will last about 6mins, just cruising along can give you 8-10mins.

Specs


Wing span: 36"
Wing-loading: 12.5oz/sq.ft
Weight: About 550gms/19.6oz
Power: GWS EDP 400, direct-drive, 8 cell 700mahr NiCd pack
Prop: GWS 6*3
Construction: 5mm hotwired Depron, High Density (31kg/m3) Styrofoam wings with 5*8mm Balsa spar.
Radio gear: 2 AC 18 18gm servos ( from Aircraft-world ), Berg 5 DSP Rx, Jeti 18amp ESC.
